Microscopio operativo 3000L

Características

Ophthalmic Surgical Microscope for Anterior and Posterior Surgery
SZX7 Olympus Optics Head Makes More Outstanding Stereo View and Colorful Micro Details
4X to 24X Zoom Magnification with Foot Panel Control for X-Y, Zoom and Focus
Eder Coaxial Assistant Microscope with Magnification 4X and 7X
Optional 30° Binocular & 0°~60° Inclinable Binocular

Acerca de Ophthalmic Operation Microscope 3000L

This 3000L surgical microscope is applied to do ophthalmic surgery of anterior and posterior segments. It applies Olympus optics head SZX7 for the wide angle and amplified fundus image with high resolution. Eder optics system also offers coaxial assistant microscope with 4X and 7X magnification.

Datos técnicos

Óptica	Olympus® SZX7
Ocular	10X campo amplio
Ángulo de observación	0°~60°
Distancia del alumno	50-76milímetros
Ajuste de dioptrías	±5D(Binocular)
Depth of Field	Manual Adjustable
Objetivo	Φ60mm Apochromatism
X-Y Speed	2.2mm/sec.Foot Control
Aumento	≥4X-20X Continually Motorized Zoom
Campo de visión	8mm ~ 50 mm
Distancia de trabajo	≥180mm
Ajuste de enfoque	Control de pie de ±20 mm
Illumination Type	Aspheric Design
Fuente de luz	Double Light 15V/150W Halogen Lamp or LED Light
Control Mode	8 Level Brightness Foot Control
Intensidad	≥60,000Lux
Power Control	~220V, 50Hz
Retinal Protection	Retinal Protection
reflejo rojo	Double Focus Multilayer Reflection
Length of Arm Extended	1260milímetros
Upper and Lower Adjustment Range	±200mm
Base Size	720mm*720mm
interruptor de pie	11 Functions: X-Y Focus/Motorized Focus and Zoom/Brightness Adjustment/Light Source Switch
Assist. Tipo de microscopio	4incógnita, 6incógnita, 10incógnita Stereo Coaxial Assistant Microscope
